Xilinx VCU118 User Manual

VCU118 Board User Guide 57
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-11: VCU118 FPGA U1 GTY Transceiver Bank 125 Connections
MGT
Bank
FPGA
(U1)
Pin
FPGA (U1) Pin
Name
Schematic Net Name
Connected
Pin
Connected Pin
Name
Connected
Device
GTY
Bank
125
AC40 MGTYTXP0_125 FMCP_HSPC_DP12_C2M_P Z28 DP12_C2M_P
FMC+ HSPC J22
AC41 MGTYTXN0_125 FMCP_HSPC_DP12_C2M_N Z29 DP12_C2M_N
AC45 MGTYRXP0_125 FMCP_HSPC_DP12_M2C_P Y14 DP12_M2C_P
AC46 MGTYRXN0_125 FMCP_HSPC_DP12_M2C_N Y15 DP12_M2C_N
AA40 MGTYTXP1_125 FMCP_HSPC_DP13_C2M_P Y30 DP13_C2M_P
AA41 MGTYTXN1_125 FMCP_HSPC_DP13_C2M_N Y31 DP13_C2M_N
AB43 MGTYRXP1_125 FMCP_HSPC_DP13_M2C_P Z16 DP13_M2C_P
AB44 MGTYRXN1_125 FMCP_HSPC_DP13_M2C_N Z17 DP13_M2C_N
W40 MGTYTXP2_125 FMCP_HSPC_DP14_C2M_P M18 DP14_C2M_P
W41 MGTYTXN2_125 FMCP_HSPC_DP14_C2M_N M19 DP14_C2M_N
AA45 MGTYRXP2_125 FMCP_HSPC_DP14_M2C_P Y18 DP14_M2C_P
AA46 MGTYRXN2_125 FMCP_HSPC_DP14_M2C_N Y19 DP14_M2C_N
U40 MGTYTXP3_125 FMCP_HSPC_DP15_C2M_P M22 DP15_C2M_P
U41 MGTYTXN3_125 FMCP_HSPC_DP15_C2M_N M23 DP15_C2M_N
Y43 MGTYRXP3_125 FMCP_HSPC_DP15_M2C_P Y22 DP15_M2C_P
Y44 MGTYRXN3_125 FMCP_HSPC_DP15_M2C_N Y23 DP15_M2C_N
AB38 MGTREFCLK0P_125 FMCP_HSPC_GBTCLK3_M2C_C_P L8 GBTCLK3_M2C_P
AB39 MGTREFCLK0N_125 FMCP_HSPC_GBTCLK3_M2C_C_N L9 GBTCLK3_M2C_N
Y38 MGTREFCLK1P_125 FMCP_HSPC_GBT1_3_P 13 Q3_P
U39 ICS855S006I
clock buffer
Y39 MGTREFCLK1N_125 FMCP_HSPC_GBT1_3_N 14 Q3_N
