Xilinx VCU118 User Manual

VCU118 Board User Guide 59
UG1224 (v1.0) December 15, 2016
www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-13: VCU118 FPGA U1 GTY Transceiver Bank 127 Connections
MGT
Bank
FPGA
(U1)
Pin
FPGA (U1) Pin
Name
Schematic Net Name
Connected
Pin
Connected Pin
Name
Connected
Device
GTY
Bank
127
H42 MGTYTXP0_127 FMCP_HSPC_DP16_C2M_P M26 DP16_C2M_P
FMC+ HSPC J22
H43 MGTYTXN0_127 FMCP_HSPC_DP16_C2M_N M27 DP16_C2M_N
L45 MGTYRXP0_127 FMCP_HSPC_DP16_M2C_P Z32 DP16_M2C_P
L46 MGTYRXN0_127 FMCP_HSPC_DP16_M2C_N Z33 DP16_M2C_N
F42 MGTYTXP1_127 FMCP_HSPC_DP17_C2M_P M30 DP17_C2M_P
F43 MGTYTXN1_127 FMCP_HSPC_DP17_C2M_N M31 DP17_C2M_N
J45 MGTYRXP1_127 FMCP_HSPC_DP17_M2C_P Y34 DP17_M2C_P
J46 MGTYRXN1_127 FMCP_HSPC_DP17_M2C_N Y35 DP17_M2C_N
D42 MGTYTXP2_127 FMCP_HSPC_DP18_C2M_P M34 DP18_C2M_P
D43 MGTYTXN2_127 FMCP_HSPC_DP18_C2M_N M35 DP18_C2M_N
G45 MGTYRXP2_127 FMCP_HSPC_DP18_M2C_P Z36 DP18_M2C_P
G46 MGTYRXN2_127 FMCP_HSPC_DP18_M2C_N Z37 DP18_M2C_N
B42 MGTYTXP3_127 FMCP_HSPC_DP19_C2M_P M38 DP19_C2M_P
B43 MGTYTXN3_127 FMCP_HSPC_DP19_C2M_N M39 DP19_C2M_N
E45 MGTYRXP3_127 FMCP_HSPC_DP19_M2C_P Y38 DP19_M2C_P
E46 MGTYRXN3_127 FMCP_HSPC_DP19_M2C_N Y39 DP19_M2C_N
R40 MGTREFCLK0P_127 FMCP_HSPC_GBTCLK4_M2C_C_P L4 GBTCLK4_M2C_P
R41 MGTREFCLK0N_127 FMCP_HSPC_GBTCLK4_M2C_C_N L5 GBTCLK4_M2C_N
N40 MGTREFCLK1P_127 FMCP_HSPC_GBT1_4_P 16 Q4_P U39
ICS855S006I
clock buffer
N41 MGTREFCLK1N_127 FMCP_HSPC_GBT1_4_N 17 Q4_N
