Chapter 3: Board Component Descriptions
Table 3-30 shows the level shifter U41 and U42 connections to FPGA U1
For more information about Pmod connector compatible Pmod modules, see the Digilent
website [Ref 21].
Table 3-30: Pmod Connector J52, J53 Connections through Level Shifter U41, U42 to FPGA U1
FPGA
(U1) Pin
Schematic Net
Name
I/O
Standard
Level Shifter
Schematic Net
Name
Pmod Connector
Pin
Side A
1.8V
Side B
3.3V
AY14 PMOD0_0_LS LVCMOS18 U41.3 U41.18 PMOD0_0 J52.1
AY15 PMOD0_1_LS LVCMOS18 U41.4 U41.17 PMOD0_1 J52.3
AW15 PMOD0_2_LS LVCMOS18 U41.5 U41.16 PMOD0_2 J52.5
AV15 PMOD0_3_LS LVCMOS18 U41.6 U41.15 PMOD0_3 J52.7
AV16 PMOD0_4_LS LVCMOS18 U41.7 U41.14 PMOD0_4 J52.2
AU16 PMOD0_5_LS LVCMOS18 U41.8 U41.13 PMOD0_5 J52.4
AT15 PMOD0_6_LS LVCMOS18 U41.9 U41.12 PMOD0_6 J52.6
AT16 PMOD0_7_LS LVCMOS18 U41.10 U41.11 PMOD0_7 J52.8
Side A
1.2V
Side B
3.3V
N28 PMOD1_0_LS LVCMOS12 U42.3 U42.18 PMOD1_0 J53.1
M30 PMOD1_1_LS LVCMOS12 U42.4 U42.17 PMOD1_1 J53.3
N30 PMOD1_2_LS LVCMOS12 U42.5 U42.16 PMOD1_2 J53.5
P30 PMOD1_3_LS LVCMOS12 U42.6 U42.15 PMOD1_3 J53.7
P29 PMOD1_4_LS LVCMOS12 U42.7 U42.14 PMOD1_4 J53.2
L31 PMOD1_5_LS LVCMOS12 U42.8 U42.13 PMOD1_5 J53.4
M31 PMOD1_6_LS LVCMOS12 U42.9 U42.12 PMOD1_6 J53.6
R29 PMOD1_7_LS LVCMOS12 U42.10 U42.11 PMOD1_7 J53.8
