Xinje DS5B Series User Manual

 High inertia motor parameters
Voltage level
220V
Motor model MS5S
60ST-
60ST-
80ST-
CS00630-20P2-S01
CS01330-20P4-S01
CS02430-20P7-S01
Motor code (brake)
50C3（58C3）
50C4（58C4）
50D1（58D1）
Encoder bit numbers
17
Rated speed [rpm]
3000
3000
3000
Max speed [rpm]
6000
6500
5000
Rated torque [Nm]
0.64
1.27
2.39
Max torque [Nm]
1.92
4.45
7.17
Overload times
3.5
3.5
3
Rated current [mA]
1900
2800
4000
Max current [mA]
6650
9800
12000
Phase resistor [mΩ]
2410
1665
990
Phase inductance [mH]
5150
2810
3300
Rotor inertia
[10
-7
kg.m
2
]
537
648
1650
Back EMF constant
[V/krpm]
35
42
54
Rated output power
[W]
200
400
750
Protection level
IP65
Motor insulation level
Class F（155℃）
Ambient temperature
－15℃～＋40℃
Ambient humidity
Relative humidity < 90% (no condensation)
