Xinje DS5C Series User Manual

67
1:IO/SON Input Signal
2: Software enabled
(panel/Modbus) panel F1-05 writes
1; Modbus writes 1 to 0x2105
register. Write 0 to cancel
enablement
3: Bus Enablation
04
Rigidity level
-
4
1-31
●
All
05
Selection of rotation direction
-
0
0~1
●
All
09
Forward direction of input pulse
command
-
0
0~1
○
6、7
10
xxx
□
0：CW/CCW
1：AB
2：P+D
-
2
0~2
○
6、7
10
x1x
□
0: Falling edge is valid
1: Rising edge is valid
-
0
0~1
○
6、7
11
Set the low position of pulses per
cycle ×1
-
0
0~999
9
√
6
12
Set the high position of pulses per
cycle ×10000
-
1
0~655
35
√
6
13
Numerator of electronic gear
-
1
1~655
35
√
6
14
Denominator of electronic gear
-
1
1~655
35
√
6
15
Pulse Frequency Corresponding to
Rated Speed in Speed Mode
*100
Hz
1000
0~100
00
○
7
16
Speed Instruction Pulse Filtering
Time
0.01
ms
100
0~100
00
○
7
23
Pulse Deviation Limit
*256
1000
0~655
√
6
