Appendix D. Hardware Specifications
iX104C
4
User’s Handbook 109
Enclosure Class Blowing rain:
4”/hr, 40 mph wind and
MIL-STD-810F Method 506.4 Procedure 1
Drip:
7 gal/ft2/hr
MIL-STD-810F Method 506.4 Procedure III
Sand and dust:
Particle size < 149 µm, 10 +
7 g/m3 particle
density 1.5 m/s
to 8.9 m/s wind speed
MIL-STD-810F Method 510.4 Procedure 1
Salt Fog:
5% saline for 48 hr (12 hr wet, 12 hr dry, 2
cycles)
MIL-STD-810F Method 509.4
Contamination by fluids:
Detergents, brake fluid, aromatic hydrocarbons
MIL-STD-810F Method 504
Solar radiation:
1120 W/m2 (355 Btu/ft2/hr) UVB @ 50° C, 7x24
hr cycles
MIL-STD-810F Method 505.4
Agency approvals
EMC • FCC Class B
• European Union Directive 2004/108/EC
Safety
• UL and CUL Listed, UL 1950, 3
rd
Edition
• TuV T-Mark, EN60950
• CSA and UL Listed, UL 1604
Environmental (continued)
