Chapter 2. Using the iX104C3
Accessing the hard disk drive compartment
52 iX104C
3
User’s Handbook
Accessing the hard disk drive compartment
When you install a new hard disk drive, follow the instructions in this
section to access the hard disk drive compartment.
WARNING Failure to follow this procedure can result in
damage to the case and the cover, which is not
covered under the Xplore Technologies warranty.
1.
Turn off the computer.
2. Remove all power from the unit, including batteries and other
power sources such as power supplies, cigarette lighter adapters,
and mobile power sources.
3. Use an M1 Philips screwdriver to remove the 10 screws from the
compartment cover. (Do not use a power screwdriver.)
5 screws
5 screws
