Chapter 2. Using the iX104C3
Accessing the hard disk drive compartment
iX104C
3
User’s Handbook 53
Re-installing the hard disk drive compartment cover
1. Make sure the sealing gasket is properly placed.
2. Reposition the cover on the compartment.
3. Use the M1 Philips screwdriver and a torque wrench to replace
the 10 screws.
Notes: Use a maximum torque of 3 kg-cm (2.6 lb-in) for each
screw.
Do not use power tools.
