iFT Series Hardware Installation Manual ADPRO

38 27817_05

8. OpenInternetExplorer,andtypethefollowingurlintheaddressbar:

http://ipaddress:controlport/login

whereipaddress istheXOdevice’sIPaddressandcontrolport isthecontrolportnumber.Forexample,with

thedefaultIPaddressandcontrolport:

http://10.0.0.10:2000/login

Thefollowingscreenappears:

9. Typetheusername(15)andpassword(defaultis666777)fortheTechnicianuser,andclickLogin.The

followingscreenappears:

Note

IftheLogin windowappearsagain,checkintheXOclientsoftwareiftheTechnicianuseris

enabled.

10. InthePin of the day box,typethecodethatyounoteddowninstep7.Includethedashes.

Default Chapter5
- Table of Contents5
