Table 44: Frame size E, line fuses, 380–480 V
Size/Type Bussmann PN* Rating Ferraz Siba
5000 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
5500 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
6000 170M6013 900 A, 700 V 6.9URD33D08A0900 20 630 32.900
* 170M fuses from Bussmann shown use the /80 visual indicator; TN/80 Type T, /110 or
TN/110 Type T indicator fuses of the same size and amperage may be substituted for
external use.
** Any minimum 500 V UL listed fuse with associated current rating may be used to meet
UL requirements.
Table 45: Frame size D, 525–690 V
OEM Fuse options
VLT model Bussmann PN SIBA PN Ferraz-Shawmut European
PN
Ferraz-Shawmut North
American PN
1500 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
2000 170M2619 20 610 31.315 6,9URD31D08A0315 A070URD31KI0315
2500 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
3000 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
3500 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
4000 170M4015 20 620 31.550 6,9URD32D08A0550 A070URD32KI0550
Table 46: Frame size E, 525–690 V
Size/type Bussmann PN* Rating Ferraz Siba
4500 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
5000 170M4017 700 A, 700 V 6.9URD31D08A0700 20 610 32.700
6000 170M6013 900 A, 700 V 6.9URD31D08A0900 20 610 32.900
* 170M fuses from Bussmann shown use the /80 visual indicator; TN/80 Type T, /110 or
TN/110 Type T indicator fuses of the same size and amperage may be substituted for
external use.
Suitable for use on a circuit capable of delivering not more than 100,000 rms symmetrical
amperes, 500/600/690 Volts maximum when protected by the above fuses.
Supplementary fuses
Table 47: SMPS fuse
D and E KTK-4 4A, 600 V
Frame size Bussmann* Rating
Table 48: Fan fuses
4500–6000, 380–480 V KLK-15 15A, 600 V
Size/Type Bussmann* LittelFuse Rating
1500–4000, 380–480 V KTK-4 4A, 600 V
1500–6000, 525–690 V KTK-4 4A, 600 V
9 Technical Specification
160 Aquavar
®
