9 Technical Specification
9.1 Power-dependent specifications
Table 37: Line power supply 380–480 V AC — Three Phase — 150 to 350 HP
Frequency Converter Type Designation 1500 2000 2500 3000 3500
Typical shaft output at 400 V [kW] 110 132 160 200 250
Typical shaft output at 460 V [hp] 150 200 250 300 350
Enclosure IP21 D5 D5 D5 D7 D7
Enclosure IP54 D5 D5 D5 D7 D7
Enclosure IP20/IP00 D3/ D3/ D3/ D4/ D4/
Enclosure 3R D1 D1 D1 D2 D2
Output current
Continuous at 400 V) [A] 212 260 315 395 480
Intermittent (60 sec overload) (at 400 V) [A] 233 286 347 435 528
Continuous (at 460/480 V) [A] 190 240 302 361 443
Intermittent (60 sec overload) (at 460/480 V) [A] 209 264 332 397 487
Continuous KVA (at 400 V) [KVA] 147 180 218 274 333
Continuous KVA (at 460 V) [KVA] 151 191 241 288 353
Maximum input current
Continuous (at 400 V) [A] 204 251 304 381 463
Continuous (at 460/480V) [A] 183 231 291 348 427
Maximum cable size, line power motor, brake and load share [mm
2
(AWG
2
)] 2 x 70
(2 x 2/0)
2 x 150
2 x 300 mcm)
Maximum external pre-fuses [A]
1
300 350 400 500 630
Estimated power loss
5)
at rated maximum load [W]
4)
, 400 V 3234 3782 4213 5119 5893
Estimated power loss
5)
at rated maximum load [W]
4)
, 460 V 2947 3665 4063 4652 5634
Weight, enclosure IP21, IP54 [kg] 96 104 125 136 151
Weight, enclosure IP00 [kg] 82 91 112 123 138
Efficiency
4)
0.98
Output frequency 0–800 Hz
Heatsink Overtemp. trip 194°F
(90°C)
230°F (110°C)
Power card ambient trip 140°F (60°C)
Table 38: Line power supply 380–480 V AC — Three Phase — 450 to 600 HP
Frequency Converter Type Designation 4500 5000 5500 6000
Typical shaft output at 400 V [kW] 315 355 400 450
Typical shaft output at 460 V [hp] 450 500 550 600
Enclosure IP21 D7 E1 E1 E1
Enclosure IP54 D7 E1 E1 E1
Enclosure IP20/IP00 D4/ /E2 /E2 /E2
Enclosure 3R D2
Output current
