Frequency Converter Type Designation 4500 5000 5500 6000
Continuous at 400 V) [A] 600 658 745 800
Intermittent (60 sec overload) (at 400 V) [A] 660 724 820 880
Continuous (at 460/480 V) [A] 540 590 678 730
Intermittent (60 sec overload) (at 460/480 V) [A] 594 649 746 803
Continuous KVA (at 400 V) [KVA] 416 456 516 554
Continuous KVA (at 460 V) [KVA] 430 470 540 582
Maximum input current
Continuous (at 400 V) [A] 590 647 733 787
Continuous (at 460/480V) [A] 531 580 667 718
Maximum cable size, line power motor, brake and load share [mm
2
(AWG
2
)] 4 x 240
(4 x 500 mcm)
Maximum cable size, brake [mm
2
(AWG
2
)] 2 x 185
(2 x 350 mcm)
Maximum external pre-fuses [A]
1
700 900
Estimated power loss
5)
at rated maximum load [W]
4)
, 400 V 6790 7701 8879 9670
Estimated power loss
5)
at rated maximum load [W]
4)
, 460 V 6082 6953 8089 8803
Weight, enclosure IP21, IP54 [kg] 263 270 272 313
Weight, enclosure IP00 [kg] 221 234 236 277
Efficiency
4)
0.98
Output frequency 0–600 Hz
Heatsink Overtemp. trip 230°F (110°C)
Power card ambient trip 154.4°F (68°C)
Table 39: Line power supply 525–690 V AC — Three Phase — 150 to 300 HP
Frequency Converter Type Designation 1500 2000 2500 3000
Typical shaft output at 550 V [kW] 110 132 160 200
Typical shaft output at 575 V [hp] 150 200 250 300
Typical shaft output at 690 V [kW] 132 160 200 250
Enclosure IP21 D5 D5 D7 D7
Enclosure IP54 D5 D5 D7 D7
Enclosure IP20/IP00 D3/ D3/ D4/ D4/
Enclosure 3R D1 D1 D2 D2
Output current
Continuous at 550 V) [A] 162 201 253 303
Intermittent (60 sec overload) (at 550 V) [A] 178 221 278 333
Continuous (at 575/690 V) [A] 155 192 242 290
Intermittent (60 sec overload) (at 575/690 V) [A] 171 211 266 319
Continuous KVA (at 550 V) [KVA] 154 191 241 289
Continuous KVA (at 550 V) [KVA] 154 191 241 289
Continuous KVA (at 690 V) [KVA] 185 229 289 347
Maximum input current
Continuous (at 550 V) [A] 158 198 245 299
Continuous (at 575 V) [A] 151 189 234 286
Continuous (at 690 V) [A] 155 197 240 296
