Frequency Converter Type Designation 1500 2000 2500 3000
Maximum cable size, line power motor, brake and load share [mm
2
(AWG
2
)] 2 x 70
(2 x 2/0)
2 x 150
2 x 300 mcm)
Maximum external pre-fuses [A]
1
315 350 350 400
Estimated power loss
5)
at rated maximum load [W]
4)
, 600 V 2963 3430 4051 4867
Estimated power loss
5)
at rated maximum load [W]
4)
, 690 V 3430 3612 4292 5156
Weight, enclosure IP21, IP54 [kg] 96 104 125 136
Weight, enclosure IP00 [kg] 82 91 112 123
Efficiency
4)
0.98
Output frequency 0–600 Hz
Heatsink Overtemp. trip 194°F
(90°C)
230°F (110°C)
Power card ambient trip 140°F (60°C)
Table 40: Line power supply 525–690 V AC — Three Phase — 350 to 450 HP
Frequency Converter Type Designation 3500 4000 4500
Typical shaft output at 550 V [kW] 250 315 355
Typical shaft output at 575 V [hp] 350 400 450
Typical shaft output at 690 V [kW] 315 400 450
Enclosure IP21 D7 D7 E1
Enclosure IP54 D7 D7 E1
Enclosure IP20/IP00 D4/ D4/ /E2
Enclosure 3R D2 D2
Output current
Continuous at 550 V) [A] 360 418 470
Intermittent (60 sec overload) (at 550 V) [A] 396 460 517
Continuous (at 575/690 V) [A] 344 400 450
Intermittent (60 sec overload) (at 575/690 V) [A] 378 440 495
Continuous KVA (at 550 V) [KVA] 343 398 448
Continuous KVA (at 575 V) [KVA] 343 398 448
Continuous KVA (at 690 V) [KVA] 411 478 538
Maximum input current
Continuous (at 550 V) [A] 355 408 453
Continuous (at 575 V) [A] 339 390 434
Continuous (at 690 V) [A] 352 400 434
Maximum cable size, line power, motor, and load share [mm
2
(AWG
2
)] 2 x 150
2 x 300 mcm)
4 x 240
(4 x 500
mcm)
Maximum cable size, brake [mm
2
(AWG
2
)] 2 x 150
(2 x 300 mcm)
2 x 185
(2 x 350
mcm)
Maximum external pre-fuses [A]
1
500 550 700
Estimated power loss
5)
at rated maximum load [W]
4)
, 600 V 5493 5852 6132
Estimated power loss
5)
at rated maximum load [W]
4)
, 690 V 5821 6149 6440
Weight, enclosure IP21, IP54 [kg] 151 165 263
Weight, enclosure IP00 [kg] 138 151 221
9 Technical Specification
