temperature where the ETR turns off the motor, the torque limit protects the motor from
being overloaded.
The ETR function is activated in [1-90] Motor Thermal Protection and is controlled in [4-16]
Torque Limit Motor Mode. The time before the torque limit warning trips the drive is set in
[14-25] Trip Delay at Torque Limit.
3.3 Dimensions
74
(2.9)
A
981
(38.6)
1166
(45.9)
310
(12.2)
163
(6.4)
420
(16.5)
417
(16.4)
380
(15.0)
177.0
(7.0)
354.0
(13.9)
1209
(45.4)
849
(33.4)
160
(6.3)
120
(4.7)
304
(12.0)
160
(6.3)
25
(1.0)
1154
(45.4)
B
C
225
(8.9)
225
(8.9)
Figure 6: D1 enclosure, cabinet mount
72
(2.8)
1362
(53.6)
1547
(60.9)
423
(16.6)
420
(16.5)
417
(16.4)
184.5
(7.3)
369.0
(14.5)
1589
(62.6)
977
(38.5)
160
(6.3)
120
(4.7)
304
(12.0)
160.0
(6.3)
25
(1.0)
1535
(60.4)
225 (8.9)
157
(6.2)
380
(15.0)
225 (8.9)
Figure 7: D2 enclosure, cabinet mount
3 Product Description
16 Aquavar
®
