Xylem Aquavar - General Technical Data

Frequency Converter Type Designation 3500 4000 4500
Efficiency
4)
0.98
Output frequency 0–600 Hz 0–500 Hz
Heatsink Overtemp. trip 230°F (110°C)
Power card ambient trip 140°F (60°C) 154.4°F
(68°C)
Table 41: Line power supply 525–690 V AC — Three Phase — 500 to 600 HP
Frequency Converter Type Designation 5000 6000
Typical shaft output at 550 V [kW] 400 450
Typical shaft output at 575 V [hp] 500 600
Typical shaft output at 690 V [kW] 500 560
Enclosure IP21 E1 E1
Enclosure IP54 E1 E1
Enclosure IP20/IP00 /E2 /E2
Enclosure 3R
Output current
Continuous at 550 V) [A] 523 596
Intermittent (60 sec overload) (at 550 V) [A] 575 656
Continuous (at 575/690 V) [A] 500 570
Intermittent (60 sec overload) (at 575/690 V) [A] 550 627
Continuous KVA (at 550 V) [KVA] 498 568
Continuous KVA (at 575 V) [KVA] 498 568
Continuous KVA (at 690 V) [KVA] 598 681
Maximum input current
Continuous (at 550 V) [A] 504 574
Continuous (at 575 V) [A] 482 549
Continuous (at 690 V) [A] 482 549
Maximum cable size, line power, motor, and load share [mm
2
(AWG
2
)] 4 x 240 (4 x 500 mcm)
Maximum cable size, brake [mm
2
(AWG
2
)] 2 x 185 (2 x 350 mcm)
Maximum external pre-fuses [A]
1
700 900
Estimated power loss
5)
at rated maximum load [W]
4)
, 600 V 6903 8343
Estimated power loss
5)
at rated maximum load [W]
4)
, 690 V 7249 8727
Weight, enclosure IP21, IP54 [kg] 263 272
Weight, enclosure IP00 [kg] 221 236
Efficiency
4)
0.98
Output frequency 0–500 Hz
Heatsink Overtemp. trip 230°F (110°C)
Power card ambient trip 154.4°F (68°C)
9.2 General technical data
Line powersupply
Supply terminals L1, L2, L3
Supply voltage 380–480 V ±10%
Supply voltage 525–690 V ±10%
9 Technical Specification
Aquavar
®
Intelligent Pump Controller - 150 HP to 600 HP INSTRUCTION MANUAL 153
