AC line voltage low/voltage drop-out: During low AC line drop-out, the adjustable
frequency drive continues until the intermediate circuit voltage drops below the minimum
stop level, which corresponds typically to 15% below the adjustable frequency drive’s
lowest rated supply voltage. Power-up and full torque cannot be expected at AC
linevoltage lower than 10% below the adjustable frequency drive’s lowest rated supply
voltage.
Supply frequency 50/60 Hz ±5%
Maximum temporary imbalance between line phases 3.0% of rated supply voltage
True power factor (λ) ≥ 0.9 nominal rated load
Displacement Power Factor (cos φ) near unity (> 0.98)
Switching on input supply L1, L2, L3 (power-ups) maximum 1 time/minute
Environment according to EN60664–1 overvoltage category III/pollutin degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS
symmetrical Amperes, 480/600 V.
Motor output (U, V, W)
Output voltage 0–100% of supply voltage
Output frequency 0–590
1)
Hz
Switching on output Unlimited
Ramp times 0.01–3,600 s
1)
Voltage and power dependent
Torque characteristics
Starting torque (constant torque) maximum 110% for 60 s
1)
Starting torque maximum 135% up to 0.5 s
1)
Overload torque (constant torque) maximum 110% for 60 s
1)
1)
Percentage relates to the adjustable frequency drive’s nominal torque.
Cable lengths and cross sections for control cables
1)
Maximum motor cable length, shielded/armored 492 ft (150 m)
Maximum motor cable length, unshielded/unarmored 984 ft (300 m)
Maximum cross-section to motor line, load sharing and
brake
1
Maximum cross-section to control terminals, rigid wire 0.0023 in
2
(1.5 mm
2
)/16 AWG (2x0.75 mm
2
)
Maximum cross-section to control terminals, flexible
cable
0.0016 in
2
(1 mm
2
)/18 AWG
Maximum cross section to control terminals, cable with
enclosed core
0.0008 in
2
(0.5 mm
2
)/20 AWG
Minimum cross-section to control terminals 0.00039 in
2
(0.25 mm
2
)
1)
Depending on voltage and power.
Digital inputs
Programmable digital inputs 4 (6)
Terminal number 18, 19, 27
1)
, 29
1)
, 32, 33
Logic PNP or NPN
Voltage level 0–24 V DC
Voltage level, logic ‘0’ PNP <5 V DC
9 Technical Specification
