1
2
3
Figure 40: Removing Gland Plate
3
2
1
Figure 41: Installing NEMA 3R Gland Plate
1. Gasket
2. Screw with captive washer
3. Gland plate
4 Mechanical Installation
Aquavar
®
Intelligent Pump Controller - 150 HP to 600 HP INSTRUCTION MANUAL 37
