Xylem hydrovar hv 1.1 User Manual

15
Variant for HV1.15-1.2:
Gasket
Thermistor
Transducer
Connection
Motor conduit box
4 mounting clamps
Center bit
4 screw
M5x50
Don’t forget the gaskets for the 3 screws .
Ensure that there is no water on the unit before you open the cover.
Mounting:
u Remove the 3 screws from the
Hydrovar cover.
u Place the centre bit in the
Hydrovar fan cover.
u Place the Hydrovar fan cover on
the motor .
u Hang the 4 clamps by the
Motor fan cover and mounted
with the 4 screws.
u Mounted the cover with the
3 screws.
