en – Original instructions
18
Position
number
Description
Tightening torque ±15%
[Nm]
[in•lbs]
1
Screw
1.4
12.4
2
Terminal Box Cover
-
-
3
Optional module with strip
-
-
4
M12 I/O cable gland
2.0
17.7
5
M20 cable gland for power supply cables
2.7
23.9
6
M16 I/O cable gland
2.8
24.8
7
Drive (single-phase model)
-
-
8
Motor
-
-
9
Screw
6.0
53.1
10
Drive (three-phase model)
-
-
11
Spacer
-
-
Pre-assembled ex factory components
Component
Quantity
Notes
Plug for Cable Gland
M12
3
M16
1
M20
1
Cable gland and lock nut
M12
3
Cable Outer Diameter:
3.7 to 7.0 mm (0.145÷0.275 in)
M16
1
4.5 to 10.0 mm (0.177÷0.394 in)
Cable Gland
M20
1
7.0 to 13.0 mm (0.275÷0.512 in)
Optional components
Component
Description
Sensors
The following sensors can be used with the unit:
• Level-sensor
RS485 Module
For the connection of a multi-pump system to a supervision system, via cable (Modbus or BACnet
MS/TP protocol)
Adaptor
M20 Metric to 1/2" NPT Adapter (item is always supplied for US market)
