3. RAM THROUGH
Using the sub-menu, it is possible to select the full-bit
output at 0dB output level.
3.RAM THROUGH
MARGIN
FULL BIT
• MAIN -9dB
3.RAM THROUGH
FULL BIT
MARGIN
3. RAMTHROUGH
サブメニューにより出力レベル0dB、フルビット出力
が選択可能です。
FULLBIT
・ MAIN-9dB
MARGIN
4Mbit
DRAM
SBL/
SBR
C/LFE
SL/SR
TIDA70Y YSS930（D1）YSS930（D0）LC89057
Analog
Digital
A/D
DIR
DECODE
DSP
POST
PROCESSING
DSP
POST
PROCESSING
DSP
PCM1804
SBL/
SBR
SWL/
SWR
ReL/
ReR
L/R
SL/SR
SL/SR
C
PL/PR
SBL/SBRorPL/PR
SWL/SWR
C
PL/PR
L/R
L/R
L/R
DIRL/R
ADL/R
RAM THROUGH
(ANALOG)
(Shaded items not used in this mode)
INPUT: DVD ANALOG
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
Input level
Each ch, -20 dBm
Volume
+6.5 dB
SPEAKER OUT
FRONT
+12.5 dBm
SUBWOOFER
OUTPUT
-5.5 dBm
CENTER
+13.5 dBm
SURROUND
+13.5 dBm
SURROUND BACK
+13.5 dBm
PRESENCE
-∞
INPUT: DVD ANALOG
SPEAKER OUT: 1kHz, SUBWOOFER OUTPUT: 50Hz
Input level
Both ch, -20 dBm
Volume
+6.5 dB
SPEAKER OUT
FRONT
+12.5 dBm
SUBWOOFER
OUTPUT
-5.5 dBm
CENTER
+13.5 dBm
SURROUND
+13.5 dBm
SURROUND BACK
+13.5 dBm
PRESENCE
-∞
