RX-V1700/DSP-AX1700
54
28.FACTORY PRESET
This menu is used to reserve and inhibit initialization of
the back-up RAM. The signals are processed using
EFFECT OFF. (The L/R signal is output using ANA-
LOG MAIN BYPASS.)
28.FAC PRESET
PRESET INN
28.FAC PRESET
PRESET RSRV
PRESET INHIBIT (Initialization inhibited) / PRESETINHIBIT(初期化禁止)
RAM initialization is not executed. Select this sub-menu to protect the values set by the
user.
RAMの初期化は行われません。ユーザーの設定値を保護するときは、こちらを選択してく
ださい。
PRESET RESERVED (Initialization reserved) / PRESETRESERVED(初期化予約)
Initialization of the back-up RAM is reserved. (Actually, initialization is executed the next
time that the power is turned on.) Select this sub-menu to reset to the original factory
settings or to reset the RAM. Any protection history will be cleared.
バックアップRAMの初期化が予約されます。(実際に初期化されるのは、次回の電源投入
時です。)工場出荷時やRAMをリセットしたいときは、こちらを選択してください。
CAUTION: Before setting to the PRESET RESERVED,
write down the existing preset memory
content of the Tuner in a table as shown
below. (This is because setting to the
PRESET RESERVED will cause the user
memory content to be erased.)
注意:PRESETRESERVEDを選んで初期化をする前に、
チューナーのユーザーメモリー内容を下表に書き写
してください。(初期化をすると、ユーザーメモ
リーの内容は消えてしまいます。)
28.FACTORYPRESET
バックアップ用RAM(音場プログラムのパラメーター
やセットメニュー内容等)初期化を予約/禁止します。
信号処理はEFFECTOFFと同じです。(ANALOGMAIN
BYPASSでL/Rを出力)
Preset group P1 P2 P3 P4 P5 P6 P7 P8
A
B
C
D
E
PRESET STATIONS / プリセット局
STATION FM FACTORY PRESET DATA (MHz)
PAGE NO. U, C R, T, K, A, B, G, E, L J
1 87.5 87.50 76.0
2 90.1 90.10 83.0
3 95.1 95.10 84.0
A/C/E
4 98.1 98.10 86.0
5 107.9 108.00 90.0
6 88.1 88.10 78.0
7 106.1 106.10 88.0
8 107.9 108.00 82.1
STATION AM FACTORY PRESET DATA (kHz)
PAGE NO. U, C, R, T, K A, B, G, E, L J
1 630 630 630
2 1080 1080 1080
3 1440 1440 1440
B/D
4 530 531 531
5 1710 1611 1611
6 900 900 900
7 1350 1350 1350
8 1400 1404 1404
29.ROM VER/SUM
The version and checksum are displayed. The signal is
processed using EFFECT OFF. The checksum is ob-
tained by adding the data at every 8 bits for each pro-
gram area and expressing the result as a 4-figure
hexadecimal data.
29.ROMVER/SUM
プログラムのバージョン、チェックサムを表示しま
す。
信号はエフェクトOFFです。チェックサムは、プログ
ラムエリア別にデータを8ビットごとに加算していき、
4桁の16進データで現したものです。
29.ROM VER/SUM
VER M023
29.ROM VER/SUM
V-VER.G014
29.ROM VER/SUM
A:816E C:A5E4
29.ROM VER/SUM
W:0000 P:9800
29.ROM VER/SUM
TI VER.:2.2r
29.ROM VER/SUM
TiSUM:CB5926CF
29.ROM VER/SUM
XM VER. A001
29.ROM VER/SUM
N.VER:
29.ROM VER/SUM
N.SUM:
29.ROM VER/SUM
A:7376 P:6596
MAIN VERSION
The version of MAIN (IC402 FUNCTION P.C.B.) firmware is displayed.
MAINIC402FUNCTIONP.C.B.)のファームウェアのバージョンを表示します
MAIN SUM
The checksum of MAIN (IC402 FUNCTION P.C.B.) is displayed.
MAINIC402FUNCTIONP.C.B.)のチェックサムを表示します。
A: All area P: Program area
VIDEO VERSION
The version of VIDEO (IC147 D-VIDEO P.C.B.) firmware is displayed.
VIDEO(IC147D-VIDEOP.C.B.)のファームウェアのバージョンを表示します。
VIDEO SUM 1
The checksum of VIDEO (IC147 D-VIDEO P.C.B.) is displayed.
VIDEO(IC147D-VIDEOP.C.B.)のチェックサムを表示します。
A: All area C: CDDA boot area
VIDEO SUM 2
The checksum of VIDEO (IC147 D-VIDEO P.C.B.) is displayed.
VIDEO(IC147D-VIDEOP.C.B.)のチェックサムを表示します。
W: Wall paper area (Not applied to these models. /
このモデルには適用されません。)
P: Program area
TI FLASH VERSION
The version of DSP (IC540 DSP P.C.B.) firmware is displayed.
DSPIC540DSPP.C.B.)のファームウェアのバージョンを表示します。
TI FLASH SUM (4Byte)
The checksum of DSP (IC540 DSP P.C.B.) is displayed.
DSPIC540DSPP.C.B.)のチェックサムを表示します。
XM VERSION (U, C models)
The version of XM firmware is displayed.
XMのファームウェアのバージョンを表示します。
Net VERSION
Not applied to these models.
このモデルには適用されません。
Net SUM
Not applied to these models.
このモデルには適用されません。
