RX-V1700/DSP-AX1700
30
RX-V1700/
DSP-AX1700
4.
SPDIF
4.
Multi
4.
DSD
4.
DSD Direct
4. HDMI AUDIO
The signals input to HDMI IN1 and IN2 are selected by
the sub-menu and output.
SPDIF
Only SPDIF is output.
Multi
Only Multi (DVD-AUDIO) is output.
4. HDMIAUDIO
HDMIIN1、IN2に入力された信号をサブメニューで選
択し、出力します。
SPDIF
SPDIFのみを出力します。
Multi
Multi(DVD-AUDIO)のみを出力します。
DSD
Not applied to these models.
DSD
このモデルには適用されません。
DSD Direct
Not applied to these models.
DSDDirect
このモデルには適用されません。
5. SPEAKERS SET
The input signal is automatically identified in the order
of dts
DOLBY DIGITAL
AAC
PCM
Analog.
There are 11 sub-menu items as follows. The signals
output from the DSP block are the same as sub-menu
MARGIN of DIAG menu No.1 DA70Y-YSS930.
5. SPEAKERSSET
入力は、dts→DOLBYDIGITAL→AAC→PCM→アナロ
グの優先順で自動判別されます。
サブメニューは以下の11つあります。
DSP部からは、No.1DA70Y-YSS930のMARGINと同
様の信号が出力されます。
FRONT: SMALL 0dB
Surround BACK: MUTE
LFE/BASS: FRONT
FATT2 GAIN
Press MIX: 5ch FATT1 GAIN
CENTER: NONE
Surround NONESurround L/R: MUTE
ZoneOn Zone Amp Tone: MAX ZoneOn Zone Amp Tone :MIN
