RX-V1700/DSP-AX1700
8
RX-V1700/
DSP-AX1700
■ SPECIFICATIONS/参考仕様
■ Audio Section / オーディオ部
Minimum RMS Output Power (Power Amp. Section) /
定格出力(パワーアンプ部) (20 Hz to 20 kHz)
FRONT L/R
U, C, R, T, K, A, B, G, E, L models (0.04 % THD, 8 ohms)
........................................................................................ 130 W + 130 W
J model (0.06 % THD, 6 ohms) ............................ 130 W + 130 W
CENTER
U, C, R, T, K, A, B, G, E, L models (0.04 % THD, 8 ohms)
.......................................................................................... 130 W
J model (0.06 % THD, 6 ohms) .......................................... 130 W
SURROUND L/R
U, C, R, T, K, A, B, G, E, L models (0.04 % THD, 8 ohms)
........................................................................................ 130 W + 130 W
J model (0.06 % THD, 6 ohms) ............................ 130 W + 130 W
SURROUND BACK L/R
U, C, R, T, K, A, B, G, E, L models (0.04 % THD, 8 ohms)
........................................................................................ 130 W + 130 W
J model (0.06 % THD, 6 ohms) ............................ 130 W + 130 W
Maximum Power / 実用最大出力 (JEITA, 1 kHz, 10 % THD)
FRONT L/R
R, T, K, L models (8 ohms) .................................. 175 W + 175 W
J model (6 ohms) ................................................. 175 W + 175 W
CENTER
R, T, K, L models (8 ohms) ................................................. 175 W
J model (6 ohms) ................................................................ 175 W
SURROUND L/R
R, T, K, L models (8 ohms) .................................. 175 W + 175 W
J model (6 ohms) ................................................. 175 W + 175 W
SURROUND BACK L/R
R, T, K, L models (8 ohms) .................................. 175 W + 175 W
J model (6 ohms) ................................................. 175 W + 175 W
Dynamic Power Per Channel / ダイナミックパワー (IHF)
FRONT L/R (8/6/4/2 ohms)
U, C, R, T, K, A, L models ............................. 160/195/255/335 W
Max. Power Per Channel/Max.パワー (1 kHz, 0.7 % THD, 4 ohms)
[B, G, E models]
FRONT L/R ............................................................. 180 W + 180 W
CENTER ................................................................................ 180 W
SURROUND L/R .................................................... 180 W + 180 W
SURROUND BACK L/R ......................................... 180 W + 180 W
Dynamic Headroom / ダイナミックヘッドルーム
U, C, R, T, K, A, L models (8 ohms) ..................................... 0.9 dB
IEC Power / IECパワー (1 kHz, 0.04 % THD, 8 ohms) [B, G, E models]
FRONT L/R ............................................................. 130 W + 130 W
Damping Factor / ダンピングファクタ
FRONT L/R (20 Hz to 20 kHz, SPEAKER-A, 8 ohms) ..... 150 or more
Input Sensitivity/Input Impedance / 入力感度/入力インピーダンス
(1 kHz, 100 W/8 ohms)
PHONO (MM) ................................................... 3.5 mV / 47 k-ohms
CD, etc. ............................................................ 200 mV / 47 k-ohms
MULTI CH INPUT
FRONT L/R, CENTER, SURROUND L/R, SUBWOOFER
.................................................................... 200 mV / 47 k-ohms
Maximum Input Signal Level / 最大許容入力
PHONO (MM) (1 kHz, 0.1 % THD) .......................... 60 mV or more
CD, etc. (1 kHz, 0.5 % THD) ...................................... 2.4 V or more
Output Level/Output Impedance / 出力電圧/出力インピーダンス
REC OUT .......................................................... 200 mV / 900 ohms
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R).................................. 1.0 V / 1.2 k-ohms
SUBWOOFER (20 Hz) ....................................... 2.0 V / 1.2 k-ohms
ZONE 2 OUT [U, C, R, T, K, A, B, G, E, L models]
.......................................................................... 1.0 V / 1.4 k-ohms
ZONE 3 OUT [U, C, R, T, K, A, B, G, E, L models]
.......................................................................... 1.0 V / 1.4 k-ohms
Headphone Jack Rated Output/Impedance / ヘッドフォン出力/出
力インピーダンス
CD, etc. (1 kHz, 40 mV, 8 ohms) ..................... 150 mV / 100 ohms
Frequency Response / 周波数特性 (10 Hz to 100 kHz)
CD, etc. to FRONT L/R (Pure direct) .............................. +0/-3.0 dB
RIAA Equalization Deviation / RIAA偏差 (20 Hz to 20 kHz)
PHONO (MM) ................................................................... 0 ±0.5 dB
Total Harmonic Distortion / 全高調波歪率(20 Hz to 20 kHz)
PHONO (MM) to REC OUT (1 V) .............................. 0.02 % or less
CD, etc. to FRONT L/R SP OUT (65 W, 8 ohms) ...... 0.04% or less
Signal to Noise Ratio / 信号対雑音比 (IHF-A network)
PHONO (MM) (Input shorted) to SP OUT
U, C, R, T, K, L models (5 mV) ............................... 86 dB or more
A, B, G, E models (5 mV) ....................................... 81 dB or more
J model (2.5 mV) ..................................................... 80 dB or more
CD, etc. (Input shorted) to SP OUT
250 mV ..................................................................100 dB or more
Residual Noise / 残留ノイズ (IHF-A network)
FRONT L/R, SP OUT ............................................... 150 µV or less
Channel Separation / チャンネルセパレーション (1 kHz/10 kHz)
PHONO ( Input shorted ) ..................... 60 dB or more/55 dB or more
CD, etc. ( Input 5.1 k-ohms shorted ) ... 60 dB or more/45 dB or more
Tone Control Characteristics / トーンコントロール特性
BASS
Boost/Cut ................................................................ ±6 dB (50 Hz)
Turnover frequency ............................................................ 350 Hz
TREBLE
Boost/Cut .............................................................. ±6 dB (20 kHz)
Turnover frequency ........................................................... 3.5 kHz
ZONE2, ZONE3 Tone Control Characteristics
[U, C, R, T, K, A, B, G, E, L models]
BASS
Boost/Cut ............................................................ ±10 dB (100 Hz)
Turnover frequency ............................................................ 450 Hz
TREBLE
Boost/Cut ............................................................ ±10 dB (10 kHz)
Turnover frequency ........................................................... 2.0 kHz
Filter Characteristics / フィルター特性
FRONT, CENTER, SURROUND, SURROUND BACK small (H.P.F.)
................... fc=40/60/80/90/100/110/120/160/200 Hz, 12 dB/oct.
SUBWOOFER (L.P.F.)
................... fc=40/60/80/90/100/110/120/160/200 Hz, 24 dB/oct.
■ Video Section / ビデオ部
Video Signal Type / ビデオ信号方式
Gray Back
U, C, R, K, J models ............................................................ NTSC
T, A, B, G, E, L models ........................................................... PAL
Video Conversion ........................................................... NTSC/PAL
Composite Video Signal Level / コンポジットビデオ信号
.............................................................................. 1 Vp-p / 75 ohms
S-Video Signal Level / Sビデオ信号
Y ............................................................................ 1 Vp-p / 75 ohms
C ..................................................................... 0.286 Vp-p / 75 ohms
Component Video Signal Level / コンポーネントビデオ信号
Y ............................................................................ 1 Vp-p / 75 ohms
Pb/Pr .................................................................. 0.7 Vp-p / 75 ohms
Maximum Input Level / 最大許容入力
VIDEO CONV. OFF .............................................. 1.5 Vp-p or more
Signal to Noise Ratio / 信号対雑音比
VIDEO CONV. OFF ................................................... 60 dB or more
Monitor Out Frequency Response / モニターアウト周波数帯域
(VIDEO CONV. OFF)
Component video signal ............................ 5 Hz to 100 MHz, ±3 dB
D5-video signal [J model] .......................... 5 Hz to 100 MHz, ±3 dB
■ FM Section / FM部
Tuning Range / 受信周波数範囲
U, C models ........................................................ 87.5 to 107.9 MHz
R, L models ............................ 87.5 to 108.0 / 87.50 to 108.00 MHz
T, K, A, B, G, E models .................................. 87.50 to 108.00 MHz
J model ................................................................. 76.0 to 90.0 MHz
50dB Quieting Sensitivity / 50dBSN感度 (IHF) (1 kHz, 100 % MOD.)
Mono ..................................................................... 2.0 µV (17.3 dBf)
Stereo..................................................................... 25 µV (39.2 dBf)
Usable Sensitivity / 実用感度 (IHF)
Mono ..................................................................... 1.0 µV (11.2 dBf)
Selectivity / 選択度
at 400 kHz ............................................................................... 70 dB
Signal to Noise Ratio / 信号対雑音比 (IHF)
Mono ....................................................................................... 76 dB
Stereo...................................................................................... 70 dB
Harmonic Distortion / 歪率 (1 kHz)
Mono ........................................................................................ 0.2 %
Stereo....................................................................................... 0.3 %
