PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section 263
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
❏ If the MATRIX channels are used individually ❏ If the MATRIX channels are paired
LEVEL knobs
Adjust the send level of the signals sent
from the MIX channels and STEREO A/B
channels to each MATRIX bus.
MIX channel 2
↓
MATRIX bus 2
MIX channel 2
↓
MATRIX bus 1
MIX channel 1
↓
MATRIX bus 1
MIX channel 1
↓
MATRIX bus 2
……
MATRIX 1 MATRIX 2
FADER
MIX CHANNEL 1
ON
ON
ON
to MATRIX1
LEVEL
to MATRIX2
LEVEL
FADER
MIX CHANNEL 2
ON
ON
ON
to
MATRIX1
LEVEL
to MATRIX2
LEVEL
PAN knobs
Adjust the panning of the signals
sent from the MIX channels and
STEREO A/B channels to each
pair of adjacent odd-numbered/
even-numbered MATRIX buses.
MIX channel 2
↓
MATRIX buses 1/2
MIX channel 1
↓
MATRIX buses 1/2
LEVEL knobs
Adjust the send level of
the signals sent from
the MIX channels and
STEREO A/B channels
to each MATRIX bus.
ON
ON
ON
ON
PAN
to MATRIX 1/2
LEVEL
……
MATRIX 1 MATRIX 2
FADER
MIX CHANNEL 1
ON
PAN
to MATRIX 1/2
LEVEL
FADER
MIX CHANNEL 2
ON
