Electrical characteristics
390 PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section
❏ Hum & Noise EIN= Equivalent Input Noise
* Hum & Noise is measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
❏ Dynamic Range
* Dynamic range is measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
❏ Input Indicator Level
❏ Sampling Frequency
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
STEREO A,B 600Ω
Master fader at nominal level and one INPUT fader at nomi-
nal level.
–128
EIN
dBu
PM5D: Rs= 150Ω, GAIN: Max., PAD: Off –64
PM5D-RH: Rs= 150Ω, GAIN: Max. –62
Master fader at nominal level and one INPUT fader at nomi-
nal level.
PM5D: Rs= 150Ω, GAIN: Min., PAD: On
PM5D-RH: Rs= 150Ω, GAIN: Min.
–81 –76
All INPUT
Master fader at nominal level and all INPUT1-48 faders at
nominal level.
PM5D: Rs= 150Ω, GAIN: Min., PAD: On
PM5D-RH: Rs= 150Ω, GAIN: Min.
–64
2TR IN ANALOG 1,2 STEREO A,B 600Ω
Master fader at nominal level.
Rs= 150Ω
–81 –76
—
STEREO A,B
600Ω
Residual Output Noise, ST Master Off
–86
MIX OUT Residual Output Noise, MIX Master Off
MATRIX OUT Residual Output Noise, MATRIX Master Off
MONITOR OUT Residual Output Noise, MONITOR Level Control Min.
CUE OUT Residual Output Noise, CUE Level Control Min.
PHONES 8Ω Residual Output Noise, PHONES Level Control Min.
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48 STEREO A,B
600Ω
PM5D: AD + DA, GAIN: Min.,
PAD: On
Fs= 44.1/48 kHz 108
dB
PM5D-RH: AD + DA, GAIN: Min. Fs= 88.2/96 kHz 106
—
STEREO A,B
DA Converter 110
MIX OUT
MATRIX OUT
MONITOR OUT
CUE OUT
Input Output Condition Min. Typ. Max. Unit
INPUT 1-48
INSERT OUT
PEAK Red LED: ON 19 21 23
dBu
SIGNAL Green LED: ON –12 –10 –8
ST IN 1-4
PEAK Red LED: ON 19 21 23
SIGNAL Green LED: ON –12 –10 –8
Parameter Conditions Min. Typ. Max. Unit
External Clock Frequency Range
Normal Rate 39.69 50.88
kHz
Double Rate 79.39 101.76
Internal Clock
Frequency
Word Clock : Int 44.1kHz 44.1
Word Clock : Int 48kHz 48
Word Clock : Int 88.2kHz 88.2
Word Clock : Int 96kHz 96
Accuracy
Word Clock : Int 44.1kHz
50 ppm
Word Clock : Int 48kHz
Word Clock : Int 88.2kHz
Word Clock : Int 96kHz
Jitter
Word Clock : Int 44.1kHz
5ns
Word Clock : Int 48kHz
Word Clock : Int 88.2kHz
Word Clock : Int 96kHz
