PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section 391
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
DSP5D
❏ Frequency Response
Fs= 44.1kHz or 48 kHz @20 Hz-20 kHz, referenced to the nominal output level @1 kHz
Fs= 88.2 kHz or 96 kHz @20 Hz-40 kHz, referenced to the nominal output level @1 kHz
❏ Gain Error Fs= 44.1 kHz, 48 kHz, 88.2 kHz or 96 kHz@1 kHz
❏ Total Harmonic Distortion Fs= 44.1 kHz or 48 kHz
* Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
❏ Total Harmonic Distortion Fs= 88.2 kHz or 96 kHz
* Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
❏ Hum & Noise Fs= 44.1 kHz, 48 kHz, 88.2 kHz or 96 kHz, EIN=Equivalent Input Noise
* Hum & Noise are measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
OMNI OUT 1-24 600Ω GAIN: Max. –1.5 0.0 0.5 dB
ST IN 1-4
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
OMNI OUT 1-24 600Ω
Input level: –62 dBu, GAIN: Max. → Output level: +4.0 dBu (Typ.) –2.0 0 +2.0
dB
Input level: +10 dBu, GAIN: Min. → Output level: +4.0 dBu (Typ.) –2.0 0 +2.0
ST IN 1-4
Input level: –62 dBu, GAIN: Max. → Output level: +4.0 dBu (Typ.) –2.0 0 +2.0
Input level: +10 dBu, GAIN: Min. → Output level: +4.0 dBu (Typ.) –2.0 0 +2.0
Internal OSC Full scale output, Output level: +24.0 dBu (Typ.) –0.5 0 +0.5
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
OMNI OUT 1-24 600Ω
+4 dBu @20 Hz–20 kHz, GAIN: Max 0.1
%
+4 dBu @20 Hz–20 kHz, GAIN: Min 0.05
ST IN 1-4
+4 dBu @20 Hz–20 kHz, GAIN: Max 0.1
+4 dBu @20 Hz–20 kHz, GAIN: Min 0.05
Internal OSC Full scale output @1 kHz 0.02
Input Output RL Conditions Min. Typ. Max. Units
INPUT 1-48
OMNI OUT 1-24 600Ω
+4 dBu @20 Hz–40 kHz, GAIN: Max 0.12
%
+4 dBu @20 Hz–40 kHz, GAIN: Min 0.05
ST IN 1-4
+4 dBu @20 Hz–40 kHz, GAIN: Max 0.12
+4 dBu @20 Hz–40 kHz, GAIN: Min 0.05
Internal OSC Full scale output @1 kHz 0.02
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
OMNI OUT 1-24 600Ω
Rs= 150Ω, GAIN: Max
Master fader at nominal level and one Ch fader at nominal level.
–128
EIN
dBu
(When controlled by PM5D or PM5D Editor) –62
Rs= 150Ω, GAIN: Min
Master fader at nominal level and one Ch fader at nominal level.
(When controlled by PM5D or PM5D Editor)
–81 –76
ST IN 1-4
Rs= 150Ω, GAIN: Max
Master fader at nominal level and one Ch fader at nominal level.
–128
EIN
(When controlled by PM5D or PM5D Editor) –62
Rs= 150Ω, GAIN: Min
Master fader at nominal level and one Ch fader at nominal level.
(When controlled by PM5D or PM5D Editor)
–81 –76
All INPUT
Rs= 150Ω, GAINs: Min
Master fader at nominal level and all ch1-48 in faders at nominal level.
(When controlled by PM5D or PM5D Editor)
–62
— Residual output noise, ST master off. –86
