Electrical characteristics
392 PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section
❏ Dynamic Range
* Dynamic range are measured with a 6 dB/octave filter @12.7 kHz; equivalent to a 20 kHz filter with infinite dB/octave attenuation.
❏ Sampling Frequency
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
OMNI OUT 1-24 600Ω
AD + DA, GAIN: Min
Fs=44.1/48 kHz 108
dBST IN 1-4 Fs=88.2/96 kHz 106
— DA Converter 110
Parameter Conditions Min Typ Max Units
External Clock Frequency Range
Normal Rate 42.9975 49.200
kHz
Double Rate 85.995 98.400
Internal Clock
Frequency
Word Clock: Int 44.1 kHz 44.1
kHz
Word Clock: Int 48 kHz 48
Word Clock: Int 88.2 kHz 88.2
Word Clock: Int 96 kHz 96
Accuracy
Word Clock: Int 44.1 kHz
50 ppm
Word Clock: Int 48 kHz
Word Clock: Int 88.2 kHz
Word Clock: Int 96 kHz
Jitter
Word Clock: Int 44.1 kHz
5ns
Word Clock: Int 48 kHz
Word Clock: Int 88.2 kHz
Word Clock: Int 96 kHz
