EQ Library List
Appendices
#Title
Parameter
LOW L-MID H-MID HIGH
01
Bass Drum
1
PEAKING PEAKING PEAKING H.SHELF
G +3.5 dB –3.5 dB 0.0 dB +4.0 dB
F 100 Hz 265 Hz 1.06 kHz 5.30 kHz
Q 1.25 10.0 0.90 —
02
Bass Drum
2
PEAKING PEAKING PEAKING LPF
G +8.0 dB –7.0 dB +6.0 dB ON
F 80.0 Hz 400 Hz 2.50 kHz 12.5 kHz
Q 1.4 4.5 2.2 —
03
Snare
Drum 1
PEAKING PEAKING PEAKING H.SHELF
G –0.5 dB 0.0 dB +3.0 dB +4.5 dB
F 132 Hz 1.00 kHz 3.15 kHz 5.00 kHz
Q 1.25 4.5 0.11 —
04
Snare
Drum 2
L.SHELF PEAKING PEAKING PEAKING
G +1.5 dB –8.5 dB +2.5 dB +4.0 dB
F 180 Hz 335 Hz 2.36 kHz 4.00 kHz
Q — 10.0 0.70 0.10
05 Tom-tom 1
PEAKING PEAKING PEAKING PEAKING
G +2.0 dB –7.5 dB +2.0 dB +1.0 dB
F 212 Hz 670 Hz 4.50 kHz 6.30 kHz
Q 1.4 10.0 1.25 0.28
06 Cymbal
L.SHELF PEAKING PEAKING H.SHELF
G –2.0 dB 0.0 dB 0.0 dB +3.0 dB
F 106 Hz 425 Hz 1.06 kHz 13.2 kHz
Q — 8.0 0.90 —
07 High Hat
L.SHELF PEAKING PEAKING H.SHELF
G –4.0 dB –2.5 dB +1.0 dB +0.5 dB
F 95 Hz 425 Hz 2.80 kHz 7.50 kHz
Q — 0.50 1.0 —
08 Percussion
L.SHELF PEAKING PEAKING H.SHELF
G –4.5 dB 0.0 dB +2.0 dB 0.0 dB
F 100 Hz 400 Hz 2.80 kHz 17.0 kHz
Q — 4.5 0.56 —
09 E. Bass 1
L.SHELF PEAKING PEAKING H.SHELF
G –7.5 dB +4.5 dB +2.5 dB 0.0 dB
F 35.5 Hz 112 Hz 2.00 kHz 4.00 kHz
Q — 5.0 4.5 —
10 E. Bass 2
PEAKING PEAKING PEAKING H.SHELF
G +3.0 dB 0.0 dB +2.5 dB +0.5 dB
F 112 Hz 112 Hz 2.24 kHz 4.00 kHz
Q 0.10 5.0 6.3 —
11 Syn. Bass 1
PEAKING PEAKING PEAKING H.SHELF
G +3.5 dB +8.5 dB 0.0 dB 0.0 dB
F 85 Hz 950 Hz 4.00 kHz 12.5 kHz
Q 0.10 8.0 4.5 —
12 Syn. Bass 2
PEAKING PEAKING PEAKING H.SHELF
G +2.5 dB 0.0 dB +1.5 dB 0.0 dB
F 125 Hz 180 Hz 1.12 kHz 12.5 kHz
Q 1.6 8.0 2.2 —
13 Piano 1
L.SHELF PEAKING PEAKING H.SHELF
G –6.0 dB 0.0 dB +2.0 dB +4.0 dB
F 95 Hz 950 Hz 3.15 kHz 7.50 kHz
Q — 8.0 0.90 —
14 Piano 2
PEAKING PEAKING PEAKING H.SHELF
G +3.5 dB –8.5 dB +1.5 dB +3.0 dB
F 224 Hz 600 Hz 3.15 kHz 5.30 kHz
Q 5.6 10.0 0.70 —
15 E. G. Clean
PEAKING PEAKING PEAKING H.SHELF
G +2.0 dB –5.5 dB +0.5 dB +2.5 dB
F 265 Hz 400 Hz 1.32 kHz 4.50 kHz
Q 0.18 10.0 6.3 —
16
E. G.
Crunch 1
PEAKING PEAKING PEAKING PEAKING
G +4.5 dB 0.0 dB +4.0 dB +2.0 dB
F 140 Hz 1.00 kHz 1.90 kHz 5.60 kHz
Q 8.0 4.5 0.63 9.0
17
E. G.
Crunch 2
PEAKING PEAKING PEAKING H.SHELF
G +2.5 dB +1.5 dB +2.5 dB 0.0 dB
F 125 Hz 450 Hz 3.35 kHz 19.0 kHz
Q 8.0 0.40 0.16 —
18 E. G. Dist. 1
L.SHELF PEAKING PEAKING H.SHELF
G +5.0 dB 0.0 dB +3.5 dB 0.0 dB
F 355 Hz 950 Hz 3.35 kHz 12.5 kHz
Q — 9.0 10.0 —
19 E. G. Dist. 2
L.SHELF PEAKING PEAKING H.SHELF
G +6.0 dB –8.5 dB +4.5 dB +4.0 dB
F 315 Hz 1.06 kHz 4.25 kHz 12.5 kHz
Q — 10.0 4.0 —
20
A. G.
Stroke 1
PEAKING PEAKING PEAKING H.SHELF
G –2.0 dB 0.0 dB +1.0 dB +4.0 dB
F 106 Hz 1.00 kHz 1.90 kHz 5.30 kHz
Q 0.9 4.5 3.5 —
21
A. G.
Stroke 2
L.SHELF PEAKING PEAKING H.SHELF
G –3.5 dB –2.0 dB 0.0 dB +2.0 dB
F 300 Hz 750 Hz 2.00 kHz 3.55 kHz
Q — 9.0 4.5 —
22
A. G.
Arpeg. 1
L.SHELF PEAKING PEAKING PEAKING
G –0.5 dB 0.0 dB 0.0 dB +2.0 dB
F 224 Hz 1.00 kHz 4.00 kHz 6.70 kHz
Q — 4.5 4.5 0.125
23
A. G.
Arpeg. 2
L.SHELF PEAKING PEAKING H.SHELF
G 0.0 dB –5.5 dB 0.0 dB +4.0 dB
F 180 Hz 355 Hz 4.00 kHz 4.25 kHz
Q — 7.0 4.5 —
24 Brass Sec.
PEAKING PEAKING PEAKING PEAKING
G –2.0 dB –1.0 dB +1.5 dB +3.0 dB
F 90 Hz 850 Hz 2.12 kHz 4.50 kHz
Q 2.8 2.0 0.70 7.0
25
Male Vocal
1
PEAKING PEAKING PEAKING PEAKING
G –0.5 dB 0.0 dB +2.0 dB +3.5 dB
F 190 Hz 1.00 kHz 2.00 kHz 6.70 kHz
Q 0.11 4.5 0.56 0.11
26
Male Vocal
2
PEAKING PEAKING PEAKING H.SHELF
G +2.0 dB –5.0 dB –2.5 dB +4.0 dB
F 170 Hz 236 Hz 2.65 kHz 6.70 kHz
Q 0.11 10.0 5.6 —
