Yamaha DSP5D - INPUT PATCH LIBRARY Screen; INPUT HA;INSERT Function; CH 1-24 (Input Channel 1-24) Screen; CH 25-48 (Input Channel 25-48) Screen

PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section 283
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
Here you can recall, store, rename, or delete items in the
input patch library.
Except for the fact that these are patch settings for input
channels, display and operations are the same as in the
OUTPUT PATCH function OUTPUT PATCH LIBRARY
screen. Refer to p.247.
INPUT HA/INSERT function
Here you can make settings for internal HAs (PM5D-RH
model only) or external HAs assigned to input channels.
INPUT PATCH LIBRARY screen
INPUT PATCH LIBRARY
CH 1-24 (Input channel 1-24) screen
CH 25-48 (Input channel 25-48)
screen
STIN/FXRTN (ST IN/FXRTN channel)
screen
CH 1-24
STIN/FXRTN
