Electrical characteristics
PM5D/PM5D-RH
All faders are nominal when measured. Output impedance of signal generator:150ohms
❏ Frequency Response Fs= 44.1 kHz or 48 kHz @20 Hz–20 kHz, referenced to the nominal output level @1 kHz
Fs= 88.2 kHz or 96 kHz @20 Hz–40 kHz, referenced to the nominal output level @1 kHz
❏ Gain Error @1 kHz
❏ Total Harmonic Distortion Fs= 44.1 kHz or 48 kHz
* Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
❏ Total Harmonic Distortion Fs=88.2 kHz or 96 kHz
* Total Harmonic Distortion is measured with a 18 dB/octave filter @80 kHz
* GAIN Max. = –60 dBu (PM5D), –62 dBu (PM5D-RH)
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48
STEREO A,B
600Ω
PM5D: GAIN: Max., PAD: Off
PM5D-RH: GAIN: Max.
–1.5
0.0 0.5 dB
MIX OUT
MATRIX OUT
MONITOR OUT
CUE OUT
PHONES 8Ω –3.0
2TR IN ANALOG 1,2
STEREO A,B
600Ω –1.5
MONITOR OUT
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48 STEREO A,B 600Ω
PM5D: Input Level: –60 dBu, GAIN: Max., PAD: Off
PM5D-RH: Input Level: –62 dBu, GAIN: Max.
2.0 4.0 6.0
dBu
PM5D: Input Level: +10 dBu, GAIN: Min., PAD: On
PM5D-RH: Input Level: +10 dBu, GAIN: Min.
2TR IN ANALOG 1,2 STEREO A,B 600Ω Input Level: +4 dBu 2.0 4.0 6.0
Internal OSC
STEREO A,B
600Ω
Full Scale Output
23.5 24.0 24.5
MIX OUT
MATRIX OUT
MONITOR OUT Full Scale Output, MONITOR Level Control: Max.
CUE OUT Full Scale Output, CUE Level Control: Max.
PHONES 8Ω –30 dBFs, PHONES Level Control: Max. –0.5 0 0.5
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48 STEREO A,B 600Ω
PM5D: +4 dBu @20 Hz–20 kHz, GAIN: Max., PAD: Off
PM5D-RH: +4 dBu @20 Hz–20 kHz, GAIN: Max.
0.1
%
PM5D: +4 dBu @20 Hz–20 kHz, GAIN: Min., PAD: On
PM5D-RH: +4 dBu @20 Hz–20 kHz, GAIN: Min.
0.05
2TR IN ANALOG 1,2 STEREO A,B 600Ω +4 dBu @20 Hz–20 kHz 0.05
Internal OSC
STEREO A,B
600Ω
Full Scale Output @1 kHz
0.02
MIX OUT
MATRIX OUT
MONITOR OUT Full Scale Output @1 kHz, MONITOR Level Control : Max.
CUE OUT Full Scale Output @1 kHz, CUE Level Control: Max.
PHONES 8Ω Full Scale Output @1kHz, PHONES Level Control: Max. 0.2
Input Output RL Conditions Min. Typ. Max. Unit
INPUT 1-48 STEREO A,B 600Ω
PM5D: +4 dBu @20 Hz–40 kHz, GAIN: Max., PAD: Off 0.1
%
PM5D-RH: +4 dBu @20 Hz–40 kHz, GAIN: Max. 0.12
PM5D: +4 dBu @20 Hz–40 kHz, GAIN: Min., PAD: On
PM5D-RH: +4 dBu @20 Hz–40 kHz, GAIN: Min.
0.05
2TR IN ANALOG 1,2 STEREO A,B 600Ω +4 dBu @20 Hz–40 kHz 0.05
Internal OSC
STEREO A,B
600Ω
Full Scale Output @1 kHz
0.02
MIX OUT
MATRIX OUT
MONITOR OUT Full Scale Output @1 kHz, MONITOR Level Control : Max.
CUE OUT Full Scale Output @1 kHz, CUE Level Control: Max.
PHONES 8Ω Full Scale Output @1kHz, PHONES Level Control: Max. 0.2
