Input/output characteristics
388 PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section
❏ Control I/O Characteristics (PM5D, PM5D-RH)
*1. XLR-3-31 type connectors are balanced. (1/Sleeve=GND, 2/Tip=HOT, 3/Ring=COLD)
*2. 4pin=HOT, 3pin=COLD, Lamp rating 5 W, Voltage control by variable volume
*3. Inputs: 4 channels, Outputs: 12 channels
Input Pin: AD Converter (7bit, 128steps, Voltage Detection Range: 0-5V, Maximum Rating: 5V)
Output Pin: Open Collector (Vmax=12V, Imax/pin=75 mA, GPO1-8: Total Imax=300 mA, GPO9-12: Total Imax=300 mA)
Power Pin: Power Supply (Vp=5V, Imax/2 pin=500 mA)
❏ Control I/O Characteristics (DSP5D)
❏ SLOT 1-4 (PM5D, PM5D-RH)/SLOT 1-2 (DSP5D) Characteristics
Terminal Format Level Connector
TO HOST USB USB 1.1
—
B Type USB Connector
MIDI
IN
MIDI DIN Connector 5PTHRU
OUT
TIME CODE IN SMPTE SMPTE 0.3Vpp(Min)/10.0Vpp(Max), 10kΩ
XLR-3-31 Type (Balanced)
*1
WORD CLOCK
IN
—
TTL/75Ω (ON/OFF)
BNC Connector
OUT TTL/75Ω
GPI
—
—
D-Sub Connector 25P (Female)
*3
HA REMOTE
RS422
D-Sub Connector 9P (Male)
RS422 REMOTE D-Sub Connector 9P (Female)
KEYBOARD
PS/2 — DIN Connector 6P
MOUSE
LAMP 1,2,3
—
2.5V - 11.5V
XLR-4-31 Type
*2
MEMORY CARD — PCMCIA (Compact Flash)
Terminal Format Level Connector
WORD CLOCK
IN — TTL/75Ω BNC Connector
OUT — TTL/75Ω BNC Connector
Ethernet 10base-T /100Base-TX 10base-T /100Base-TX RJ-45
Card Name Function Input Output
The Number Of Usable Cards
PM5D/PM5D-RH DSP5D
MY4-AD
ANALOG IN
4IN
—
4
2
MY8-AD
8IN
—
MY8-AD24
2
MY8-AD96
MY4-DA
ANALOG OUT —
4OUT
MY8-DA96 8OUT
MY8-ADDA96 ANALOG IN/OUT 8IN 8OUT
MY8-AE
AES/EBU
8IN 8OUT
MY8-AEB
MY8-AE96
MY8-AE96S
MY16-AE 16IN 16OUT
MY8-AT
ADAT
8IN 8OUT
MY16-AT 16IN 16OUT
MY8-TD
TASCAM
8IN 8OUT
MY16-TD 16IN 16OUT
MY16-C
CobraNet 16IN 16OUT
—
MY16-CII
2
AVIOM16/o-Y1 A-NET 16IN 16OUT
MY16MADI64 MADI 16IN 16OUT
AVY16-ES EtherSound 16IN 16OUT
Waves Y96K Effect & I/O 8IN 8OUT —
