PM5D/PM5D-RH V2 / DSP5D Owner’s Manual Reference section 383
Information shown
in the display
Function
menu
Global
functions
Output
functions
Input
functions
Appendices
DSP5D
Sampling Frequency
Internal: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
External: 42.9975 kHz to 49.200 kHz (Normal Rate)
85.995 kHz to 98.400 kHz (Double Rate)
Signal Delay
Less than 2.5 ms INPUT to OMNI OUT (@Fs=48kHz)
Less than 1.25 ms INPUT to OMNI OUT (@Fs=96kHz)
Maximum Voltage Gain 86 dB INPUT1-48/ST IN1-4 to OMNI OUT1-24
Crosstalk (@1kHz) –80 dB Adjacent Input Channels (INPUT1-48/ST IN1-4), GAIN: Min.
Dimensions 480 x 460 x 440 mm (W x D x H)
Net Weight 38 kg
Power Requirements 300W
AC Power Cord Length 250cm
Operation free-air Temperature Range +10 °C to +35 °C
Storage Temperature Range –20 °C to +60 °C
Included Accessories
Owner’s Manual
AC Power Cord
D-Sub 68-pin Cable 10 m x 2
Optional Accessories
mini YGDAI cards
Power Supply PW800W
Power Supply Link Cable PSL360
