A
DECBFGHIJKLMNOPQR
DTX-MULTI 12
DM CIRCUIT DIAGRAM 2/2 (002) (DTX-MULTI 12)
DM CIRCUIT DIAGRAM 2/2 (002) (DTX-MULTI 12)28CC1-2001051725-2 5
2
CPU (SWX02)
CPU (SWX02)
P2ROM 256M FLASH ROM 512M
INVERTER
INVERTER
DAC
DAC
REGULATOR +5V
USB HIGH-SIDE
POWER SW.
Not installed
to LCD MODULE
USB
TO DEVICE
TO HOST
to PN-CN501
<Page 8: T-2>
to JK-CN302
<Page 6: J-6>
to JK-CN301
<Page 6: J-5>
to JK-CN303
<Page 6: J-8>
Not installed
: Not installed（未実装）
: Ceramic Capacitor （セラミックコンデンサー）
<D-11>
<D-11>
<N-3>
<O-7>
<O-7>
<O-3>
<D-9>
<D-10>
<D-11>
<E-10>
<O-5>
<O-10>
<001 F-4>
<001 F-4>
<001 E-5>
<001 N-8>
<001 M-7>
<001 M-7>
<001 N-8>
<001 N-8>
<001 M-9>
<001 N-9>
<001 N-10>
<001 N-8>
<D-9>
<001 N-9>
<001 N-9>
<001 O-11>
NJM78M05DL1A (XS534A00)
REGULATOR +5V
DM: IC4
1: INPUT
2: GND
3: OUTPUT
1
2
3
1SS372 (V9424900)
DIODE ARRAY
DM: DA1–4
1
3
2
1
2
3
1: ANODE 1
2: CATHODE 2
3: CATHODE 1,
ANODE 2
D1F60 (VS20110R)
DIODE 1.0A 600V
DM: D1
1: ANODE
2: CATHODE
2
1
2SA1037AK (VV556500)
TRANSISTOR
DM: TR1, TR4
1: BASE
2: EMITTER
3: COLLECTOR
1
3
2
1
2
3
2SC2412K (VV556400)
TRANSISTOR
DM: TR2, TR3
1
2
3
1: EMITTER
2: BASE
3: COLLECTOR
1
2
3
