Yamaha DTX - Specifications

139
Appendix
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
Specifications
Tone Generator
16-bit AWM2 (Compliant to GM Standard
Level 1)
Polyphony
Maximum of 32 notes
Voices
928 Drum and Percussion Voices, 128 Normal
Keyboard Voices
Modes
Drum Kit Mode
Play Mode: 32 preset drum kits and 32 user
drum kits
Trigger Edit Mode: 31 functions
Voice Edit Mode: 21 functions
Chain Mode
Play Mode: 16 types of chains (maximum of 32
steps)
Edit Mode: 3 functions
Pattern Mode
Play Mode: 660 preset patterns (110 styles x 6
sections), 100 user patterns
Record Mode: Real-time or step recording,
recording tracks (chord, bass, rhythm)
Job Mode: 7 functions
Song Mode
Play Mode: 100 preset songs, 30 user songs
Record Mode: Real-time or step recording,
recording tracks (TR1/TR2 sequencer tracks,
pattern/chord/tempo tracks)
Job Mode: 11 functions
Store Mode
Drum Kit Store, Chain Store
Utility Mode
System, MIDI, equalizer, sequence, multi-
timbre
Effect
Reverb (hall1/2, room1/2/3, stage1/2, plate,
white, tunnel, canyon, basement)
Chorus, variation (preset for each voice)
Controls
Volume Slider (MASTER, AUX IN, ACCOMP/
SNARE/CYMBAL, CLICK/KICK/MISC.), Data
Scroll Wheel, Mode buttons (DRUM KIT,
CHAIN, SONG, PATTERN, TRIGGER, VOICE,
UTILITY, STORE), PAGE¡/⁄ (MAIN A/B),
Q Cursor button (FILL AB/BA), -1/
NO(INTRO), +1/YES (ENDING), TEMPO,
SHIFT, TR1 (MISC.), TR2 (CYMBAL), BASS/
TMP TR (SNARE), RHYTHM/PAT TR (KICK),
CHORD/CHO TR, SOLO, Transport buttons
(CLICK, PAUSE, REWIND, START/STOP,
FORWARD, RECORD), CONTRAST knob
Display
Custom LCD display
2-digit large segment LED
8 mute/sequencer operation LEDs
Input Jacks
1 SNARE–8 H.HAT, 10/9 KICK, 12/11, AUX IN
Output Jacks
PHONES, OUTPUT(L/MONO,R), AUX OUT(L/
R)
Foot Switch/Control Jacks
FOOT SW, H.HAT CONTROL
MIDI Jacks
MIDI IN/OUT
Power Requirements
DC 12V
Dimensions
300mm (W) x 57mm (D) x 220mm (H)
Weight
1.4kg
Included Accessories
Owner’s Manual
AC power adapter (PA-1207 or PA-3B)
