Yamaha F20A Service Manual

8-7
E
–+
ELEC
WIRE HARNESS
WIRE HARNESS (E)
WIRING DIAGRAM
CDEFGHIJKLMN
1234567890AB
AB
A
A
B
B
1
1
2
2
3
3
4
4
5
67 8
5678
9
0
0
A
A
B
B
C
C
D
D
9
9
9
13 14 15 18 19 20 22 24 1 2 6 9 10
R/W P Y
W
Br
R
P
B
G
Y
W/G B Br B B B B B BP
B
O
G
R R
R
B
P/W B/W G/W
W/G
Y/B Br/B R/W
B/W
Y/B
Br/B Br/B
P O G/W Y/R
Y/R
P/W
Y/B
Y
Y/B
Br/B Y
Connect to:
1 Remote control
2 Low-oil-pressure warning
lamp
3 Electrothermal ram
4 CDI unit
5 Starter relay
6 Oil pressure switch
7 Charge coil
8 Electrothermal valve coil
9 Ground
0 Engine temperature sensor
A Pulser coil
B Ignition coil
C Rectifier/regulator
D Fuse
B : Black
Br : Brown
G : Green
O : Orange
P : Pink
R : Red
W : White
Y : Yellow
B/W : Black/white
Br/B : Brown/black
G/W : Green/white
P/W : Pink/white
R/W : Red/white
W/G : White/green
Y/B : Yellow/black
Y/R : Yellow/red
