TROUBLESHOOTING
ENGINE DOES NOT START
ELECTRIC STARTING SYSTEM
The starter motor fails to turn.
No. Checking steps Possible remedy
1 Check the battery.
• Clean the battery terminals.
• Recharge or replace the battery.
2
Check the starter motor operation.
(Refer to “CHECKING THE STARTER MOTOR OPERA-
TION” on page 5-8)
If the starter motor operates normally,
the starter motor is OK.
3
Check the starter motor.
(Refer to “ELECTRIC STARTING SYSTEM” on page 5-10)
Repair or replace the starter motor.
4 Check the main switch. Replace the main switch.
5
Check the entire starting system’s wiring.
(Refer to “CIRCUIT DIAGRAM” on page 5-1)
Properly connect or repair the starting
system’s wiring.
6 The starting system circuit is OK. —
