Yamaha MX800V - MUFFLER (for Models Equipped with a Muffler)

3-4
1
2
3
4
5
6
7
8
9
10
ENGINE
MUFFLER (For models equipped with a muffler)
MUFFLER (For models equipped with a muffler)
Order Job/Parts to remove Q’ty Remarks
Removing the muffler Remove the parts in the order listed.
1 Muffler 1
2 Spark arrester 1
3Gasket 2
1
2
3
3.5 N・m (0.35 kgf・m, 2.6 lb・ft)
20 N・m (2.0 kgf・m, 15 lb・ft)
20 N・m (2.0 kgf・m, 15 lb・ft)
