ENGINE
RECTIFIER/REGULATOR
RECTIFIER/REGULATOR
Order Job/Parts to remove Q’ty Remarks
Removing the rectifier/regulator Remove the parts in the order listed.
1 Earth terminal 1
2 Engine hunger 1 For maintenance.
3 Rectifier/regulator lead connector 2 Disconnect.
4 Rectifier/regulator 1
20 N・m (2.0 kgf・m, 15 lb・ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
1
3
4
2
To Next Page
