FUEL
4-1
FUEL
FUEL PUMP
Order Job/Parts to remove Q’ty Remarks
Removing the fuel pump Remove the parts in the order listed.
1 Fuel filter 1
2 Fuel hose 1
3Fuel pump 1
4 Fuel pump bracket 1
5 Pulsar hose 1
6 Fuel delivery hose 1
7 N・m (0.7 kgf・m, 5.2 lb・ft)
1
2
3
6
5
4
