TROUBLESHOOTING
OTHER TROUBLES
THE BATTERY IS NOT CHARGED
No. Checking steps Possible remedy
1 Check the battery.
• Clean the battery terminals.
• Recharge or replace the battery.
2
Check the stator coil.
(Refer to “CHECKING THE STATOR COIL ASSEMBLY” on
page 5-7)
Replace the stator coil assembly.
3
Check the rectifier/regulator.
(Refer to “CHECKING THE RECTIFIER/REGULATOR” on
page 5-8)
Replace the rectifier/regulator.
4
Check the entire charging system’s wiring.
(Refer to “CIRCUIT DIAGRAM” on page 5-1)
Properly connect or repair the charging
system’s wiring.
5 The charging system circuit is OK. —
