SPECIFICATIONS
MAINTENANCE SPECIFICATIONS
Oil pump:
Inner-rotor-to-outer-rotor-tip
clearance
0.19–0.35 mm (0.008–0.013 in)
Relief valve operating pressure 342–538 kPa (3.42–5.38 kgf/cm², 49.59–78.01 psi)
Carburetor:
Type 7UC-10 (MX800V)
7UC-00 (MX825V)
I.D. mark 7UC-E4101-10 (MX800V)
7UC-E4101-00 (MX825V)
Bore size ø28
Main jet 1.19 mm (0.046 in) (Left)/1.15 mm (0.045 in) (Right)
Main air jet 1.2 mm (0.047 in)
Pilot air jet 0.9 mm (0.035 in)
Pilot outlet 0.95–1.05 mm (0.037–0.041 in)
Valve seat size 1.58–1.62 mm (0.062–0.063 in)
Main nozzle 2.5 mm (0.0984 in)
Pilot jet 0.46 mm (0.018 in) (Left)/0.46 mm (0.018 in) (Right)
Pilot screw 1.75–4.25 turns out
Throttle valve 17
Governor assembly:
Tension spring attach hole 4
Engine speed:
High engine speed (with no load) 3550–3650 r/min
Low engine speed (with no load) 1650–1750 r/min
