SPECIFICATIONS
TIGHTENING TORQUES
Governor assembly bolt M6  1.0 8 N·m (0.8 kgf·m, 5.9 lb·ft)
Intake manifold nut and bolt M6  1.0
1st: 3.0 N·m (0.30 kgf·m, 2.2 lb·ft)
2nd: 7 N·m (0.7 kgf·m, 5.2 lb·ft)
Starter motor assembly bolt M8  1.25 23 N·m (2.3 kgf·m, 17 lb·ft)
Earth terminal nut M8  1.25 9 N·m (0.9 kgf·m, 6.6 lb·ft)
Starter motor rear bracket bolt M6  0.8 6 N·m (0.6 kgf·m, 4.4 lb·ft)
Starter relay nut M6  1.0 11 N·m (1.1 kgf·m, 8.1 lb·ft)
Drain screw — 1.4 N·m (0.14 kgf·m, 1.0 lb·ft)
Float chamber screw — 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Float screw — 1.0 N·m (0.10 kgf·m, 0.73 lb·ft)
Throttle valve screw — 1.6 N·m (0.16 kgf·m, 1.2 lb·ft)
Choke valve screw — 1.6 N·m (0.16 kgf·m, 1.2 lb·ft)
Pilot jet screw — 1.8 N·m (0.18 kgf·m, 1.3 lb·ft)
Main jet (Left, Right) — 1.4 N·m (0.14 kgf·m, 1.0 lb·ft)
Item Thread size Tightening torque
