91
11
NOTICE
● Attachthehook-and-loopfastener(male)atbothedgesofbelttoentiresurface.
(7) Slide the belt and adjust the two (2) belt edges to the vi-
cinity of vehicle center as much as possible.
NOTICE
● Thebeltedgesshouldnotbeneartheframeortouchingmovingparts(asshownincorrectly
in the “NG” inset drawing).
● Makesurethebeltistaut.Aslackorloosebeltcouldallowthebatterybagtocomeo󰀨orthe
belt could get caught in moving parts.
Belt
Belt Edge
NG
Belt Edge
Frame Belt
Frame
(8) Feed the band part of battery bag through upper side
frame and x the belt by using tting tape (Hook-and-loop
fastener of male at both sides).
There are two (2) ways for tting tape attaching methods
as follows; Select the method adequate to the wheel-
chair you are using and attach the tape.
Battery Bag
Band Part of
Battery Bag
Frame
