En 105
❑ Center
Selects whether or not a center speaker is connected and its size.
Settings
❑ Surround
Selects whether or not surround speakers are connected and its size.
Settings
❑ Surround Back
Selects whether or not surround back speakers are connected and its size.
Settings
• “Surround Back” is automatically set to “None” when “Surround” is set to “None”.
❑ Front Presence
Selects whether or not front presence speakers are connected.
Settings
❑ Subwoofer
Selects whether or not subwoofer is connected and its phase.
Settings
• When the bass sound is lacking or unclear, switch the subwoofer phase.
❑ Extra Bass
Sets the speakers to produce the front channel low-frequency components.
Settings
• This setting is not available when “Subwoofer” is set to “None” or “Front” is set to “Small”.
Large
Select this for large speaker.
The center speaker will produce all of the center channel frequency
components.
Small (default)
Select this for small speaker.
The subwoofer will produce center channel low-frequency components
(configurable in “Bass Cross Over”).
None
Select this when no center speaker is connected.
The front speakers will produce center channel audio.
Large
Select this for large speakers.
The surround speakers will produce all of the surround channel
frequency components.
Small (default)
Select this for small speakers.
The subwoofer will produce surround channel low-frequency
components (configurable in “Bass Cross Over”).
None
Select this when no surround speakers are connected.
The front speakers will produce surround channel audio. Virtual
CINEMA DSP works when you select a sound program.
Large x1
Select this when 1 large speaker is connected.
The surround back speaker will produce all of the surround back channel
frequency components.
Large x2
Select this when 2 large speakers are connected.
The surround back speakers will produce all of the surround back channel
frequency components.
Small x1
Select this when 1 small speaker is connected.
The subwoofer will produce surround back channel low-frequency
components (configurable in “Bass Cross Over”).
Small x2
(default)
Select this when 2 small speakers are connected.
The subwoofer will produce surround back channel low-frequency
components (configurable in “Bass Cross Over”).
None
Select this when no surround back speakers are connected.
The surround speakers and subwoofer (or front speakers) will produce
surround back channel audio.
Use (default) Select this when front presence speakers are connected.
None Select this when no front presence speakers are connected.
Use
Normal
(default)
Select this when a subwoofer is connected (not to reverse the phase).
The subwoofer will produce LFE (low-frequency effect) channel audio
and low-frequency components from other channels.
Reverse
Select this when a subwoofer is connected (reverse the phase). The
subwoofer will produce LFE (low-frequency effect) channel audio and
low-frequency components from other channels.
None
Select this when no subwoofer is connected. The front speakers will
produce LFE (low-frequency effect) channel audio and low-frequency
components from other channels.
Off (default)
Depending on the size of the front speakers, either the subwoofer or
front speakers produce the front channel low-frequency components.
On
Both the front speakers and subwoofer produce the front channel low-
frequency components.
