Types of information
■ Audio Signal
Displays information about the current audio signal.
• Even when this unit is set to output bitstream signals directly, the signal may be converted depending on
the specifications and settings of the playback device.
■ Video Signal
Displays information about the current video signal.
■ HDMI Monitor
Displays information about the TVs connected to the HDMI OUT jacks.
Use the cursor keys ( / ) to switch between “OUT1” and “OUT2”.
■ Network
Displays the network information on this unit.
■ System
Displays the system information on this unit.
• If this unit detects a newer firmware over the network, “!” (exclamation mark) appears at the upper right of
the “Information” and “System” icons, and the corresponding message will be displayed in this screen. You
can update the firmware of this unit by pressing ENTER in this screen and following the procedure in
“Updating the firmware of this unit” (p.124).
■ Zone
Displays information about Zone2.
Input
Format Audio format of the input signal
Channel
The number of source channels in the input signal (front/
surround/LFE)
For example, “5.1 (3/2/0.1)” means 5.1ch in total (3 front
channels, 2 surround channels, and LFE).
Sampling The number of samples per second of the input digital signal
Bitrate The amount of data per second of the input bitstream signal
Dialogue The dialogue normalization level of the input bitstream signal
Output The speaker terminals from which signals are output
HDMI Signal Presence or absence of HDMI signal input/output
HDMI Resolution Resolutions of input signal (analog or HDMI) and output signal (HDMI)
Analog Resolution
Resolutions of input signal (analog) and signal output at the MONITOR
OUT jacks (analog)
HDMI Error
Errors related to HDMI
HDCP Error: The TV does not support HDCP (High-bandwidth Digital
Content Protection).
Device Over: The number of devices connected to the HDMI OUT jack is
over the limit.
Interface TV interface
Video Resolution Resolutions supported by the TV
IP Address IP address
Subnet Mask Subnet mask
Default Gateway The IP address of the default gateway
DNS Server (P) The IP address of the primary DNS server
DNS Server (S) The IP address of the secondary DNS server
MAC Address MAC address
Status Network connection status
Remote ID The remote control ID setting of the main unit (p.119)
TV Format The video signal type setting of this unit (p.119)
Speaker Impedance The speaker impedance setting of this unit (p.118)
System ID System ID number
Firmware Version The version of firmware installed on this unit
Input The input source selected for Zone2
Volume The volume setting for Zone2
