6-1
E
JET
PUMP
Intake grate and ride plate
Intake grate and ride plate removal
Step
Procedure/Part name
Q’ty Service points
1Bolt 2
2Bolt 8
3 Intake grate 1
4Screw 4
5 Speed sensor 1 FX SHO
Speed and water temperature
sensor
1 FX Cruiser SHO
6 Ride plate 1
7 Spacer 1
Reverse the removal steps for installation.
2
5
4
2
1
3
6
2
7
LT
572
LT
LT
572
LT
LT
242
LT
LT
242
LT
LT
242
LT
6 × 30 mm
8 N
·
m (0.8 kgf
·
m, 5.9 ft
·
Ib)
8 × 35 mm
17 N
·
m (1.7 kgf
·
m, 12.5 ft
·
Ib)
5 × 12 mm
4 N
·
m (0.4 kgf
·
m, 3.0 ft
·
Ib)
LT
572
LT
Intake grate and ride plate
