Yamaha WaveRunner FX Cruiser SHO User Manual

8-50
E
HULL
HOOD
1
2
3
4
5
6
7
8
9
Deck and hull
Deck and hull disassembly 1
Step
Procedure/Part name
Q’ty Service points
1Bolt 2
2 Bow eye 1
3 Nut/washer 8/8
4Bolt 2
5 Front protector 1 2
NOTE:
Apply soapy water to the inner surfaces a of
the grommets before installing the projec-
tions b of the front protectors.
6Grommet 4
7 Front protector 2 1
8Rivet 9
Not reusable
9 Rear protector 2
10 Rivet 10
Not reusable
13 N
·
m (1.3 kgf
·
m, 9.6 ft
·
Ib)
6 × 20 mm
5 × 12 mm
6 × 15 mm
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
6 × 25 mm
2 N
·
m (0.2 kgf
·
m, 1.5 ft
·
Ib)
16 N
·
m (1.6 kgf
·
m, 11.8 ft
·
Ib)
8 × 40 mm
1
2
3
4
17
15
16
5
7
572
LT
6
3
LT
242
12
14
13
b
8
8
9
18
19
10
11
LT
271
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
5 N
·
m (0.5 kgf
·
m, 3.7 ft
·
Ib)
a
Deck and hull
