E
ELEC
– +
1
2
3
4
5
6
7
8
9
7-44
2. Check:
• Electric bilge pump operation
Does not operate → Replace the elec-
tric bilge pump.
Checking steps:
1. Remove the electrical bilge pump.
Refer to “Transom plate and hose
removal” in Chapter 6.
2. Suspend the electric bilge pump in a con-
tainer filled with water.
3. Connect the positive battery lead to the
terminal 1, and the negative battery lead
to the terminal 2.
4. Check that water flows from the electric
bilge pump hose 3.
3
Br
1
2
B
Fuel system
Fuel injector
1. Check:
• Fuel injector operation sound
Does not sound → Measure the fuel
injector input voltage.
Checking steps:
1. Connect a computer to the watercraft to
use the YDIS.
2. Using the “Stationary test” of the YDIS, lis-
ten for the fuel injector operation sound.
Control system / Fuel system
To Next Page
