6-17
E
JET
PUMP
8. Install:
• Spacer 1
• Impeller 2
NOTE:
The impeller has left-hand threads. Turn the
impeller counterclockwise to tighten it.
Drive shaft holder 3:
YB-06201
Drive shaft holder 6 3:
90890-06520
T
R
.
.
Impeller:
110 N·m (11.0 kgf·m, 81.1 ft·lb)
LOCTITE 572
2
1
LT
572
LT
AA
3
Impeller duct and impeller housing
installation
1. Install:
• Dowel pins 1
• Impeller duct assembly 2
• Dowel pins 3
• Nozzle 4
• Bolts 5
NOTE:
Clean the contacting surfaces before applying
sealant.
T
R
.
.
Impeller duct bolt:
40 N·m (4.0 kgf·m, 29.5 ft·lb)
LOCTITE 572
1
1
2
3
4
5
3
1194E
1194E
LT
572
LT
Impeller duct and drive shaft
To Next Page
