8-40
E
HULL
HOOD
1
2
3
4
5
6
7
8
9
Shift cable installation (jet pump end)
1. Install:
• Shift cable
NOTE:
To adjust the shift cable. Refer to “Shift cable
check and adjustment” in Chapter 3.
Shift cable set length a (jet pump
end):
13.0 ± 0.8 mm (0.51 ± 0.03 in)
T
R
.
.
Shift cable locknut (jet pump end):
2.9 N·m (0.29 kgf·m, 2.1 ft·lb)
LOCTITE 572
a
LT
572
LT
Remote control cables and speed sensor lead
To Next Page
